Allen-Bradley 1762-IR4
The Allen-Bradley 1762-IR4 is a four-input resistance module part of the MicroLogix 1200 series. Manufactured by Rockwell Automation, it supports various RTD and resistance signals, ensuring compatibility with MicroLogix 1100, 1200, and 1400 controllers. It features a sigma-delta converter and a range of input filters for precise temperature measurements.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Function | Resistance Module |
| Part Number/Catalog No. | 1762-IR4 |
| Converter Type | Sigma-Delta |
| Product Family | MicroLogix |
| Inputs | 4 |
| Heat Dissipation | 1.5 Watts |
| Product Type | RTD / Resistance Input Module |
| No. of Inputs | Four (4) |
| UPC | 10611320861676 |
| Compatible RTD Sensors | RTD Type100? Platinum 385, 200? Platinum 385, 500? Platinum 385 ,1000? Platinum 385, 100? Platinum 3916, 200? Platinum 3916, 500? Platinum 3916, 1000? Platinum 3916, 10? Copper 426, 120? Nickel 672, 120? Nickel 618 and 604? Nickel-Iron 518 RTD, 2-Wire, 3-Wire, 4-Wire RTD |
| Compatible Resistance signals | 0 to 150?, 0 to 500?, 0 to 1000? and 0 to 3000? |
| Compatible Controllers | MicroLogix 1100 / 1200 / 1400 |
| Data Formats | raw/proportional, engineering units x 1, engineering units x 10, scaled-for-PID and percent full scale |
| Input Filters | 10 Hz, 50 Hz, 60 Hz, 250 Hz, 500 Hz and 1 kHz |
| Resolution | Input filter and configuration dependent. |
| Conversion Method | Delta-Sigma |
| Configuration software | RSLogix 500 |
