Schneider Electric ATV312H075N4
The ATV312H075N4 is a variable speed drive from the Altivar 312 range, designed for asynchronous motors in simple machines. This compact drive provides 0.75 kW (1 HP) power, operates on a 380 to 500 V three-phase supply, and features an integrated EMC filter and sensorless flux vector control.
| Range of Product | Altivar 312 |
| Product or Component Type | Variable speed drive |
| Product destination | Asynchronous motors |
| Product Specific Application | Simple machine |
| Assembly style | With heat sink |
| component name | ATV312 |
| Motor power kW | 0.75 kW |
| Maximum Horse Power Rating | 1 hp |
| [Us] rated supply voltage | 380...500 V - 15...10 % |
| Supply frequency | 50...60 Hz - 5...5 % |
| Phase | 3 phase |
| Line current | 3.6 A 380 V, Isc = 5 kA 2.7 A 500 V |
| EMC filter | Integrated |
| Apparent power | 2.4 kVA |
| Maximum transient current | 3.5 A 60 s |
| Power dissipation in W | 41 W at nominal load |
| Speed range | 1…50 |
| Asynchronous motor control profile | Sensorless flux vector control with PWM type motor control signal Factory set : constant torque |
| Electrical connection | Al1, Al2, Al3, AOV, AOC, R1A, R1B, R1C, R2A, R2B, LI1...LI6 terminal 0.00 in² (2.5 mm²) AWG 14 L1, L2, L3, U, V, W, PA, PB, PA/+, PC/- terminal 0.01 in² (5 mm²) AWG 10 |
| Supply | Internal supply for logic inputs 19...30 V 100 mA overload and short-circuit protection Internal supply for reference potentiometer (2.2 to 10 kOhm) 10...10.8 V 10 mA overload and short-circuit protection |
| communication port protocol | CANopen Modbus |
| IP degree of protection | IP20 on upper part without cover plate IP21 on connection terminals IP31 on upper part IP41 on upper part |
| Option card | Communication card CANopen daisy chain Communication card DeviceNet Communication card Fipio Communication card Modbus TCP Communication card Profibus DP |
