Schneider Electric ATV71HU22N4
The ATV71HU22N4 is a 2.2kW, 3HP variable speed drive designed for complex machinery, featuring a 480V power supply, integrated EMC filter, and graphic terminal. It supports up to 100 meters of unshielded motor cable and includes a heat sink for durability, making it suitable for demanding industrial environments.
| Range of Product | Altivar 71 |
| Product or Component Type | Variable speed drive |
| Product Specific Application | Complex, high-power machines |
| Component name | ATV71 |
| Motor power kW | 2.2 kW, 3 phase 380...480 V |
| Maximum Horse Power Rating | 3 hp, 3 phase 380...480 V |
| Maximum motor cable length | 164.04 ft (50 m) shielded cable 328.08 ft (100 m) unshielded cable |
| power supply voltage | 380...480 V - 15...10 % |
| Phase | 3 phase |
| Line current | 7.1 A 480 V 3 phase 2.2 kW / 3 hp 8.2 A 380 V 3 phase 2.2 kW / 3 hp |
| EMC filter | Integrated |
| Assembly style | With heat sink |
| Apparent power | 5.4 kVA 380 V 3 phase 2.2 kW / 3 hp |
| Prospective line Isc | 5 kA 3 phase |
| Nominal output current | 4.8 A 4 kHz 460 V 3 phase 2.2 kW / 3 hp 5.8 A 4 kHz 380 V 3 phase 2.2 kW / 3 hp |
| Maximum transient current | 8.7 A 60 s 3 phase 2.2 kW / 3 hp 9.6 A 2 s 3 phase 2.2 kW / 3 hp |
| Output frequency | 0.1…599 Hz |
| Nominal switching frequency | 4 kHz |
| Switching frequency | 1...16 kHz adjustable 4...16 kHz with derating factor |
| Asynchronous motor control profile | Sensorless flux vector control (SFVC) (voltage or current vector) Flux vector control (FVC) with sensor (current vector) Voltage/frequency ratio (2 or 5 points) ENA (Energy adaptation) system for unbalanced loads |
| Type of polarization | No impedance Modbus |
